140t Per Hour Limestone Industrial Grinding Mill

140t Per Hour Limestone Industrial Grinding Mill

  • High Light

    140t Industrial Grinding Mill

    ,

    Limestone Industrial Grinding Mill

    ,

    140t Ball Mill In Cement Plant

  • Housing Material
    Q235A
  • Type
    Vertical Type
  • Ground Material
    Limestone,
  • Power
    As Per The Type
  • Place of Origin
    JIANGSU,CHINA
  • Brand Name
    Pengfei
  • Certification
    ISO,CE,
  • Model Number
    PFM
  • Minimum Order Quantity
    1 set
  • Price
    USD600000-USD6000000
  • Packaging Details
    All the packing is suitable for the ocean transporting and inland transporting,1.The kiln shell is transported in 6 sections. 2.The supports is packed on the cushion.3. the small parts is packed in wooden box and iron frame.4.there will be shipping mark on
  • Delivery Time
    180 days
  • Supply Ability
    1 SET PER 180days

140t Per Hour Limestone Industrial Grinding Mill

140t Per Hour Limestone Industrial Grinding Mill



Scope of business: The company has the great comprehensive ability to provide best quality services on turn-key basis with technology design, complete plant, erection and debugging, commissioning for the 10000t /d rotary kiln cement production enterprise. It can also undertake various projects abroad international bidding projects. It supplies complete equipments and technical services of grinding, calcination, crushing, dust collecting, conveying and lifting for the metallurgy, the chemical industry, the electrical power, the mine, the environmental protection enterprises, etc.



Brief Introduction of Jiangsu Pengfei Group Co., Ltd.

Location advantage: Jiangsu Pengfei Group Co., Ltd. is located in Nantong City which is in the north of Yangtze River delta economic metropolitan area. It connects Yellow Sea in the east and looks south to the Yangtze River. The company is the national famous building material machinery manufacturing and transporting base. The goods will be shipped to focus all over the world by the million tons of seagoing vessel will through the international Nantong Port and Shanghai Port. Ningqi Railway and Xinchang Railway connect here, and at the same time the coastal Highway and Haili Highway also link here. Because of its special harbor location advantages and manufacturing capacity, Pengfei Group has become the largest cement equipment manufacturing and exporting base in our national coastal areas.



No. Instruction of parameter Unit Technical parameter Remarks
0 Vertical Mill set 1
  Type   PVM4540C
  Ground material   Clinker
  Inlet material size mm ≤30
  Material moisture % ≤7
  Product finess   ≤60 microns Clinker+gypsum and other mixed material
  Product moisture % ≤0.5
  Capacity t/h 100
  Gas temperature outlet of mill 80~90









1.General Condition

Model HRM&Model PRM roller mills are new equipment designed by digesting and assimilating advanced technology introduced from other countries.it through grinding rollers to roll and press the materials(0-40mm)on the rotating grinding pan with pressure and grind them to be reached up to the relevant finess.it has good advantages of high griding efficiency.big drying capacity.product finess is easy to be adjusted.low noise,low power consumption,simple process flow.low abrasiveness,operating cost saving and etc.

under the same process conditions and rotating speed.grinding pan diameter material level.grinding roller pressure are all the same,grinding efficency of Model PRM roller mill can be raised more than 30%,average power consumption can be saved about 8.2%,and impact vibration of the overall unital could be obviously reduced.

With international advanced technology and national leading manufacturing quality.it has passed the ministry-level test and listed as state level new preouct in 1995

2.The technical parameter

1.The inlet size is less than 80mm

2.The permited inlet moisture is 6%.

3.The mill speed is 29.75r/min

3.The specification of roller mill





Workshop 140t Per Hour Limestone Industrial Grinding Mill 0
