Dry Process OPC 100tph Integrated Cement Plant

Dry Process OPC 100tph Integrated Cement Plant

  • High Light

    100tph Integrated Cement Plant

    ,

    OPC Integrated Cement Plant

    ,

    100tph Clinker Grinding Plant

  • Process
    Dry Process
  • Working Hours
    24 Hours
  • Automatic Level
    Completely Automatically
  • Voltage
    380V,10kV,6.6kV,11kV
  • Weight
    As Per Process
  • Workign Days
    330 Days
  • Color
    As Per Your Requirements
  • After Sales Service
    Yes
  • Warranty Period
    One Year
  • Place of Origin
    Jiangsu
  • Brand Name
    Pengfei
  • Certification
    CE,ISO
  • Model Number
    1000tpd
  • Minimum Order Quantity
    1 set
  • Price
    USD8000000-USD16000000
  • Packaging Details
    All the packing is suitable for the ocean transporting and inland transporting,1.The kiln shell is transported in 6 sections. 2.The supports is packed on the cushion.3. the small parts is packed in wooden box and iron frame.4.there will be shipping mark on
  • Delivery Time
    360 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1 SET PER 360 DAYS

Dry Process OPC 100tph Integrated Cement Plant

                                            WELCOME TO JIANGSU PENGFEI GROUP CO.,LTD



Dry Process OPC 100tph Integrated Cement Plant



1. PRODUCT DESCRIPTION



² 1.1..1 Limestone crushing and transportation

Trucked to the site from the its mine, limestone is directly discharged at an exclusive tipple, and crushed in the single-stage hammer crusher via heavy-duty plate feeder .When the crusher is off, limestone is kept in exclusive pile, later sent to crushing system



² 1.1..2 Limestone pre-blending & transportation

Crushed limestone is to be stored in the round preblending stockpile,and storage life of 3.74days. the crushed limestone will be continously piled through cantilever stacking belt conveyor in chevron shape,and then transversely reclaimed by scrapper reclaimer.the limestone after preblending will be conveyed to raw material proportioning station by belt conveyor.



² 1.1..3 Clay & Marl crushing and Iron powder transportation

Trucked to the site from the its mine, clay and marl directly discharged at an exclusive tipple, and crushed in the crusher via medium plate feeder .When the crusher is off, clay is kept in exclusive pile, later sent to crushing tipple by frontloader. After crushing, the clay and marl then be sent to the Accessory Raw Material Preblending shed by belt conveyors.

The Iron powder with particle size £25mm is discharged from automatic dump truck into hopper. Then be sent to the Accessory Raw Material Preblending shed by belt conveyors.



² 1.1.4 United Preblending Shed & Transportation

Crushed clay, marl and Iron powder carried to Accessory Raw Material Preblending Shed by belt conveyor to stored. United preblending stockpile consists of auxiliary preblending stockpile and raw coal preblending stockpile. The United Preblending Shed is a longitude stockpile.



² 1.1..5 Raw material proportioning & transportation

Raw meal proportioning shall employ four silos, and weighing belt of frequency control. The proportioning silo of limestone is of φ8m steel bin , while clay, marl and iron powder proportioning silo is of steel bin.



² 1.1..6 Raw mill & waste gas treatment at kiln inlet

After meeting the requirements of grindability test, raw meal shall enter into vertical mill made in China.



² 1.1.7. Raw meal blending silo & kiln inlet feeding

Raw meal from raw mill is to be stored in IBAU silo, impact flow meter shall be employed at kiln inlet feeding, and raw meal is to be carried into pre-heater system by belt type bucket elevator



² 1.1.8 Kiln pre-heater & pre-calciner system

Kiln inlet employs single line 5 stage cyclone pre-heater and KSF calciner.



² 1.1.9 Calcining kiln & kiln outlet

After pre-calcining processing, raw meal is calcined into clinker in rotary kiln , with heat consumption as 760kCal/kg-cl. High temperature clinker from rotary kiln is to be cooled sharply by cold air blown in below from grid plate in grate cooler. The temperature of clinker from grate cooler is ambient temperature + 65, cooled and crushed clinker is taken into clinker silo by bucket chain conveyor.Part of high temperature exhaust gas from cooler shall become secondary air; other part shall become combustion air in calciner via tertiary air duct; and part of it shall become drying source for coal grinding in coal mill; and the rest shall be released into the atmosphere after the treatment of kiln outlet bag filter. Fine ash from heat exchanger and bag filter shall be carried into clinker silo via chain conveyor and clinker bucket chain conveyor.



² 1.1.10 Clinker storage & transportation

The cooled and crushed clinker through chain bucket conveyer comes to clinker silo for storage, with capacity of 33000t, and storage life of 16.5 days. The clinker out of silo is sent to the clinker batch silo before cement mill by belt conveyor.



² 1.1.11 Gypsum crushing and pozzolana transportation

The gypsum and pozzolona is transported to crusher for crushing .When the crusher is off, gypsum is kept in exclusive pile, later sent to crushing tipple by frontloader. After crushing, the gypsum then be sent to the batch silo by belt conveyors.

Trucked to the site from the its mine, pozzolana directly discharged at the additives shed. Then it is conveyed via forklift to specific unloading pit and via belt conveyer sent to proportioning silo.



² 1.1.12 Cement proportioning and grinding

Cement proportioning shall employ threeφ8m silos, and weighing belt of frequency control.

Cement mill has two sets of circulating system. The ground cement will go through chute and elevator, then be directly sent to Φ15m cement silos.



² 1.1.13 Cement storage and bulking

Cement from cement mill system is stored in four silos , two of them equip bulk loading system. Cement is carried to packing system from the silo bottom. The storage capacity for one cement silo is 8700t.



² 1.1.14 Cement packing

Cement from bottom of silos is lifted by the bucket elevator. Packing shall employs rotary packer with 8 mouths, and cement bagged are transported by belt conveyor to bag cement truck loader system. There are four belt-loaders in truck loader system,for packaged truck loading.



² 1.1.15 Raw Coal Crushing&Transportation

Trucked to the site from the its mine, coal directly discharged at an exclusive tipple, and crushed in the crusher via medium plate feeder .When the crusher is off, coal is kept in exclusive pile, later sent to crushing tipple by frontloader. After crushing, the coal then be sent to the raw coal Preblending shed by belt conveyors.



² 1.1.16 Pulverized coal preparation and weighing system

Raw coal after measuring of belt scale is fed into air swept mill for drying and grinding. The hot air for drying is exactly the exhaust gas from kiln outlet grate cooler. Discharged coal powder will be collected by specific high concentrated anti explosive bag filter, the collected powder then enters pulverized coal bin, through 2 measuring systems, which will be sent to multichannel coal burner pipe at kiln outlet and coal burner pipe at kiln inlet calciner. The dusty gas is purified by bag filter and then ejected to atmosphere.



² 1.1.17 Compressed air station

There are two air compressor stations in the site, that is, 6 sets of screw air-boosting compressor in all of 23m3/min as displacement and the pressure is 0.8Mpa. One air compressor station is set below the kiln pre-heater frame with 3 sets screw air-boosting compressor, the other which is near the proportioning silo of cement mill shop can meet the demands of every pneumatic valve, kiln pre-heater block-up, measuring device and pulsed bag dust collector and so on.







Product type and material required



Table 1

Name OPC PPC PFC PSC
CLINKER
GYPSUM
SLAG
FLY ASH
POZZOLONA



2.ABOUT US


Company history

Established in 1994 and with a registered capital of 51.3859 million yuan, Jiangsu Pengfei Group Co., Ltd is a hi-tech enterprise specializing in undertaking overall contracting projects of designing, manufacturing, supplying, assembling, debugging and technical serving for industries like building materials, environmental protection, metallurgy, and chemical machineries. Our products mainly consist of cement production line, rotary kiln, ball mill, raw mill, slag mill, cement grinding equipment, preheating equipment, laterite nickel rotary kiln, oxidized pellet production line, air swept coal mill, mining mill, autogenous mill, semi-autogenous mill, rolling machine, powder separator, vertical mill, crushing equipment, environmental protection equipment, cooling machine, drying equipment, fluidized bed furnace, compound fertilizer equipment, blending machine, granulator, vibrating screen, proportioning scale, conveyor, feeding machine, air slide, elevator, chemical evaporimeter, conditioning tower, electrical control equipment, liquid ammonia tank, etc. As the leading manufacturer of cement equipment in China, we have the largest production and export base of cement equipment in the coastal areas, and all of our products have passed the certification of ISO9000 and CE.

Our company covers an area of 450,000m2, of which 240,000 m2 is our assembly workshop, and now we have six subsidiaries that are respectively dedicated to machinery, electron, foundry, assembly and new building material. Our machinery and equipment manufacture base has an annual productivity of 300,0000tonnes and we have our own storage and transport bases at ports. Located near the Chinese international ports of Shanghai and Nantong, we have the advantage of convenient transportation. Our products have been well received in as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt,, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Bolivia, etc.

We have successfully accomplished the manufacture task of four 3000t/d cement production lines for Pakistan, and undertook eight cement production lines for Burma. We also provide overall cement engineering project service in South Africa, Rwanda, Egypt, Bengal, Azerbaijan, Russia, Turkey, Vietnam, Bolivia, Brazil, Peru, and so on. Our services range from limestone crushing to cement supply, and from assembling and debugging to technology serving.

Product Advantages:
Here in Jiangsu Pengfei Group Co., Ltd, we have a wide range of product lines for customers, and we provide overall contracting services for cement production enterprises, including technological design, equipment supply, and assembly and debugging of equipment. And we undertake international biding projects as well. Moreover, we also provide equipment and technical service for grinding, calcining, crushing, dust collecting and transporting in enterprises like metallurgy, chemical industry, mining, electricity, and environment protection, etc.

1. Cement production line: for this line, we provide various services including engineering design, civil construction, equipment, assembly and debugging, technology services, and general contracting service.
2. Cement grinding plant: our cement grinding plant has advantages of simpler processing flow, easier operation, less investment, electricity saving, and environmental protection, and it can be mixed with admixture.
3. Industrial kiln and furnace: our industrial kiln and furnace is widely used in fields like metallurgy, chemical industry, building refractories, environmental protection sector, and that.
4. Grinding equipment: it is typically designed for grinding various ores and grindable materials for industrial and mining enterprises, and it can also be used for open-circuit grinding as well as circulatory closed-circuit grinding in conjunction with the powder classifier.
5. Crushing equipment: our crushers are typically designed for coarse and medium crushing of ores and other materials.
6. Dust collector: this kind of equipment is typically used in fields like metallurgy, electricity, chemical industry, building material, and many other sectors.
7. Cooling equipment: our monocular cooler has features of compact, rational and simple structure, high thermal efficiency, low maintenance costs, less equipment investment and high-efficiency operation. And all of our coolers have the advantages of high efficiency and low operation costs.
8. Drying machine: our rotary dryer is mainly used for drying slag, clay, limestone and more in fields of cement, chemical engineering, metallurgy, building material, etc.
9. Compound fertilizer equipment: this kind of machine features easy technology, low investment and convenient operation.

3.PACKING TYPE AND SHIPPING

1. Export packing

All the packing are suitable for the sea-worthy packing and inland packing. the big parts like the shell for main equipments are all bared packing with obvious hoist point.the motor and gear box ,electrical parts are all packed by wooden box with COFF or packed with plywood.the parts which is made by steel or alloy are packed by iron cradle.



1.1Maching capacity

Dry Process OPC 100tph Integrated Cement Plant 0

2.1000tpd cement production line

2.1Construction scale

 To build a production line of 1000t/d clinker cement, that is, to produce 1000 tons of cement clinker each day, 300,000 tons per year, to produce portland cement more than 347,100 tons. The output will vary according to product variety and class.

Model selection of process: To adopt the advanced technology in dry 5-stage cyclone preheater, calciner and rotary kiln, which is developed and manufactured by China.

2.2Process description

(1) Limestone crushing and transportation

After limestone is conveyed from mine to plant, if crusher is switched on, LS will be directly unloaded to receiving pit, and then by heavy duty apron feeder sent to single hammer crusher PCF1616 to be crushed, if crusher is switched off, LS will be unloaded to open-air stockpile, and then sent to receiving bin via loader for crushing.

The crushed limestone is sent to two limestone dosing silos (dia.Φ12m) by belt conveyer, elevator and tee valve.

(2) Auxiliary material crushing and conveying

When the exclusive receiving pit is free, clay is unloaded directly to the pit, and then sent to clay proportioning silo via apron feeder, tooth crusher, belt conveyer and elevator. When the receiving pit is full, clay will be firstly stacked at shed, and then conveyed by forklift to receiving pit when it is free, at last, it is conveyed to clay proportioning silo by apron feeder, crusher, belt conveyer and clay proportioning silo.

When the exclusive receiving pit is free, iron ore and sandstone is unloaded directly to the pit, and then sent to respective proportioning silo via raw crusher, elevator. When the receiving pit is full, they will be firstly stacked at shed, and then conveyed by forklift to receiving pit when it is free, at last, it is conveyed to respective proportioning silo by crusher and elevator.

(3) Coal homogenization

Raw coal is unloaded directly to the pit after coming into plant, and then sent to raw coal preblending stockpile via apron feeder, belt conveyer, elevator and belt conveyer with discharging trolley, or firstly unloaded to open-air stockpile, and then conveyed by forklift to receiving pit subject to inform, at last, it is conveyed to raw coal preblending stockpile through apron feeder, belt conveyer, elevator and belt conveyer with discharging trolley. The blended raw coal is sent to raw coal bin through forklift and belt conveyer.

(4) Raw material proportioning silo and conveying

Raw material proportioning silo is composed of two concrete silos and three steel slab bins, and be measured by variable speed belt scale. Limestone silo consists of two Φ12m concrete silos, used for storage and proportioning. The proportioning bins is Φ6m,Φ6m and Φ6m respectively for clay, sandstone and iron ore.

(5) Raw mill & waste gas treatment at kiln inlet

Proportioned raw material will be fed onto the air swept drying mill with size of Φ3.8×8.6m. In the process of rotating, raw meal will be raised by material raising device in the raw mill and sufficiently contact with hot gas from high-temperature fan at kiln inlet. By this means, raw meal will be dried. Dry raw meal is ground in the mill. Then the raw meal will fed onto high efficiency separator. Fine powder will be fed onto the raw meal-homogenizing silo via electric flap valve and air slide while coarse powder returned to the mill via electric flap valve and air slide. Hot gas from preheater goes through humidification tower and high-temperature fan and then divides into two parts, one part goes directly to electric dust collector, and the other part goes to raw mill head, and then 1/8 of this part goes to mill end. Waste gas out of mill firstly goes through high efficiency separator and raw mill fan (with inlet regulation valve), and joins the waste gas to the electric dust collector. After that, the waste gas will be purified by the electric dust collector and drained to the air.

2.3 Main equipment photos

Dry Process OPC 100tph Integrated Cement Plant 1

3.Quality control system

Dry Process OPC 100tph Integrated Cement Plant 2

Dry Process OPC 100tph Integrated Cement Plant 3



4.After-sales service

Implementing the concept of pre-sale, in-sale and after-sale service:

1 Pre sale service:

Introducing products and related processes to users,Production Line Scheme and Technical Advantage,Providing pre-project technical advisory services,Customized Production Line Technical Solution for Customers.

2 Sale service:Manufacture excellent products for users,Provide customers with confidence in product quality.

Test:Strengthening Process Inspection and Intermediate Control,Strict Inspection System,Guarantee product quality,Providing quality products.

Train:Arrange experienced engineering technicians for training and guidance

install:Delegate engineers and technicians with experience in installation and commissioning to the site for installation and commissioning guidance,After customer acceptance is satisfactory,Qualified user opinion reports must be obtained.

3 After-sale service:

Regular guidance to users for product maintenance and maintenance,Free guidance for user installation,commissioning and product maintenance.Upon receipt of user failure handling requirements,Give maintenance advice within 24 hours.

Customer satisfaction is our constant pursuit, Always put the interests of customers first.

5.Certificate

Dry Process OPC 100tph Integrated Cement Plant 4
